MEAN WELL XLC-60-24-S LED Driver, W/Strain-Relief, LED Lighting, 60 W, 24 VDC, 2.5 A, Constant Voltage, 110 V
MEAN WELL XLC-60-24-S LED Driver, W/Strain-Relief, LED Lighting, 60 W, 24 VDC, 2.5 A, Constant Voltage, 110 V
Product Overview
XLC-60-24-S is an XLC-60 series 60W constant power and constant voltage output LED driver. XLC-60 is designed based on the latest safety regulations with 3 in 1 and DALI-2 dimming. XLC-60 can also be adjusted for brightness with a push button as a simple way dimming, so it provides more flexibility for LED lighting application. Typical applications include recessed light, downlight, panel light, commercial lighting, decorative lighting, LED strip lighting and DALI digital lighting.
- Constant voltage mode output of 24V and 2.5A default current
- Voltage range from 110 to 305VAC (155 to 400VDC) and 47 to 63Hz frequency range
- Plastic housing with class ? and PFC design
- Meet UL8750 Class 2 / Class P power unit
- Flicker free, complying with CE ErP directive
- Stand by power consumption <lt/>0.5W
- Meet emergency lighting (EL) application
- Minimum dimming level 0.1% (DALI-2DT6)
- 5 years warranty
- With strain-relief (independent casing type )
Product details
Other details
| Brand | MEAN WELL |
| Part Number | XLC-60-24-S |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
