Bourns SRU1048-470Y Power Inductor (SMD) 47 µH 1.7 A Shielded 1.5 SRU1048 Series 10mm x 4.8mm
Bourns SRU1048-470Y Power Inductor (SMD) 47 µH 1.7 A Shielded 1.5 SRU1048 Series 10mm x 4.8mm
- Available in E6 series
- Unit height of 4.8mm
- -40 to 125°C Operating temperature range
Power Management, Industrial, Portable Devices, Communications & Networking, Consumer Electronics, Automotive
Product details
| Inductance | 47µH |
| RMS Current (Irms) | 1.7A |
| Inductor Construction | Shielded |
| Saturation Current (Isat) | 1.5A |
| Product Range | SRU1048 Series |
| Power Inductor Case | 10mm x 10mm x 4.8mm |
| DC Resistance Max | 0.094ohm |
| Inductance Tolerance | ± 30% |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | BOURNS |
| Part Number | SRU1048-470Y |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
