XP POWER JCA0305D01 3 Watt 2:1 Input Range Dual Output DC/DC Converter, Input 4.5V to 9V, Output ± 5V/300mA
XP POWER JCA0305D01 3 Watt 2:1 Input Range Dual Output DC/DC Converter, Input 4.5V to 9V, Output ± 5V/300mA
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 3W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 300mA |
| Output Voltage - Output 2 | -5V |
| Output Current - Output 2 | 300mA |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | JCA Series |
| Input Voltage DC Min | 4.5V |
| Input Voltage DC Max | 9V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | CE, CSA, UL |
| Width | 20.3mm |
| Height | 10mm |
| Depth | 25.4mm |
Other details
| Brand | XP POWER |
| Part Number | JCA0305D01 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
