Tracopower TVN 5-2415WI Isolated Board Mount DC/DC Converter 1 Output 5 W 24 V 208 mA
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 5W |
| Output Voltage - Output 1 | 24V |
| Output Current - Output 1 | 208mA |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | TVN 5WI Series |
| Input Voltage DC Min | 9V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed, Adjustable |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Width | 20mm |
| Height | 10.2mm |
| Depth | 32mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TVN 5-2415WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
