TRACOPOWER TMR 0510 Isolated Board Mount DC/DC Converter, Regulated, 1 Output, 2 W, 3.3 V, 500 mA
TRACOPOWER TMR 0510 Isolated Board Mount DC/DC Converter, Regulated, 1 Output, 2 W, 3.3 V, 500 mA
- Full SMD design
- High efficiency
- Excellent load and line regulation
- Indefinite short-circuit protection
- 1000VDC I/O Isolation
- Remote on/off control
- -40 to +85�C Operating temperature range
Applications
Power Management, Communications & Networking, Industrial
Product details
| Output Power Max | 2W |
| Input Voltage DC Min | 4.5V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 21.8mm |
| Width | 9.2mm |
| Product Range | - |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 3.3V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 9V |
| Output Current - Output 1 | 500mA |
| Height | 11.1mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 0510 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
