TRACOPOWER TME 1205S Isolated Board Mount DC/DC Converter, Miniature, Fixed, 1 Output, 10.8 V, 13.2 V, 1 W, 5 V
TRACOPOWER TME 1205S Isolated Board Mount DC/DC Converter, Miniature, Fixed, 1 Output, 10.8 V, 13.2 V, 1 W, 5 V
The TME 1205S is a 1-output board-mount Isolated DC/DC Converter. A high efficiency allows a wide operating temperature range of -40 to +85°C. It requires only 0.7cm² board space. It provides a cost effective solution to generate supplementary, isolated voltages. Full SMD-design and a 100% production test of parameters ensure a high reliability.
- 12VDC Nominal input voltage
- 71% Efficiency
- 1000VDC I/O isolation
- ±0.02%/K Temperature coefficient
- 33µF Maximum capacitive load
- 90kHz Switching frequency
- 100% Burn-in (8 hour)
Applications
Power Management
- :
- 1W
- :
- 10.8V
- :
- Through Hole
- :
- -
- :
- -
- :
- 11.5mm
- :
- 6.1mm
- :
- -
- :
- SIP
- :
- -
- :
- -
- :
- 5V
- :
- -
- :
- 1 Output
- :
- Fixed
- :
- 13.2V
- :
- 200mA
- :
- 10.2mm
Product details
| Output Power Max | 1W |
| Input Voltage DC Min | 10.8V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 11.5mm |
| Width | 6.1mm |
| Product Range | - |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 13.2V |
| Output Current - Output 1 | 200mA |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TME 1205S |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
$8.05
TRACOPOWER TME 1205S Isolated Board Mount DC/DC Converter, Miniature, Fixed, 1 Output, 10.8 V, 13.2 V, 1 W, 5 V—
$8.05
TRACOPOWER TME 1205S Isolated Board Mount DC/DC Converter, Miniature, Fixed, 1 Output, 10.8 V, 13.2 V, 1 W, 5 V
