TRACOPOWER THN 15-2423 Isolated Board Mount DC/DC Converter, 2 Output, 15 W, 15 V, 500 mA, -15 V, 500 mA
TRACOPOWER THN 15-2423 Isolated Board Mount DC/DC Converter, 2 Output, 15 W, 15 V, 500 mA, -15 V, 500 mA
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 15W |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 1 | 500mA |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 500mA |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | THN 15 Series |
| Input Voltage DC Min | 18V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | IEC, UL |
| Width | 25.4mm |
| Height | 9.9mm |
| Depth | 25.4mm |
Other details
| Brand | TRACOPOWER |
| Part Number | THN 15-2423 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
