TRACOPOWER TEN 30-2432WIN Isolated Board Mount DC/DC Converter, Metal Case, 3 Output, 30 W, 5 V, 4 A, 15 V, 330 mA
TRACOPOWER TEN 30-2432WIN Isolated Board Mount DC/DC Converter, Metal Case, 3 Output, 30 W, 5 V, 4 A, 15 V, 330 mA
Product details
| No. of Outputs | 3 Output |
| Output Power Max | 30W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 4A |
| Output Voltage - Output 2 | 15V |
| Output Current - Output 2 | 330mA |
| Output Voltage - Output 3 | -15V |
| Output Current - Output 3 | 330mA |
| Product Range | - |
| Input Voltage DC Min | 9V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | - |
| Width | 25.4mm |
| Height | 10.2mm |
| Depth | 50.8mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 30-2432WIN |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
