Traco Power THL 6-2421WISM Isolated Surface Mount DC/DC Converter ITE 4:1 6 W 2 Output 5 V 600 mA

The THL 6-2421WISM from Tracopower is a THL 6WISM series, 6W DC to DC converter. THL 6WISM series is a family of compact 6W DC/DC converter with 4:1 input voltage range. The product is available in SMD-package which is 31% smaller than a standard DIP-24 package. The internal filter to meet EN55022 Class A without external components makes this converter easy to design in. It comes with remote On/Off and short circuit protection. THL 6WISM converter is an excellent solution for data and telecom applications and for instrumentation and industrial electronics.

• Input voltage range is 9VDC to 36VDC (nominal 24VDC)
• Output voltage is ±5VDC
• Output current is ±600mA
• Typical efficiency is 82%
• I/O isolation voltage is 1500VDC, maximum I/O isolation capacitance is 1500pF
• I/O isolation resistance is >1Gohm at (500VDC)
• Input current at no load is 20mA typical, input current at full load is 300mA
• Switching frequency is 330KHz
• IEC 60950-1, UL 60950-1 safety standard

Applications

Industrial

Footnotes NRND - Not Recommended for New Designs

Other details

Brand	TRACO POWER
Part Number	THL 6-2421WISM
Quantity	Each
Technical Data Sheet EN
CAD Multiple Formats EN
