XP POWER ECE05US12 5 Watt AC/DC PCB Mount Single Output Power Supply, Input 85V to 264V, Output 12V/410mA
XP POWER ECE05US12 5 Watt AC/DC PCB Mount Single Output Power Supply, Input 85V to 264V, Output 12V/410mA
- Ultra Compact Size, from 1"x1"
- Encapsulated PCB Mount
- Class II Construction
- <0.3 W No Load Input Power
- Peak Load Capability
Product details
| Power Supply Output Type | Fixed |
| Output Power Max | 5W |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Input Voltage AC Max | 264V |
| Depth | 25.4mm |
| Width | 25.4mm |
| Input Voltage AC Min | 85V |
| Product Range | ECE Series |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| Output Current - Output 1 | 410mA |
| Height | 15.24mm |
Other details
| Brand | XP POWER |
| Part Number | ECE05US12 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
