EPCOS B72210S0250K101 TVS Varistor, MOV, 25 V, 31 V, StandarD Series, 77 V, Disc 10mm, Metal Oxide Varistor (MOV)
EPCOS B72210S0250K101 TVS Varistor, MOV, 25 V, 31 V, StandarD Series, 77 V, Disc 10mm, Metal Oxide Varistor (MOV)
Product details
| Operating Temperature Min | -40°C |
| Clamping Voltage Vc Max | 77V |
| Peak Surge Current @ 8/20µs | 500A |
| Voltage Rating V DC | 31V |
| Operating Temperature Max | 85°C |
| Varistor Case Style | Disc 10mm |
| Product Range | StandarD Series |
| Automotive Qualification Standard | - |
| Varistor Type | Metal Oxide Varistor (MOV) |
| Peak Energy (10/1000uS) | 3.7J |
| Voltage Rating V AC | 25V |
Other details
| Brand | EPCOS |
| Part Number | B72210S0250K101 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
