EBM-PAPST R2E180-CB28-01 Fan Blower, R2E Series, Motorized Impeller, 230 V, AC, 180 mm, 54.5 mm, 450 m³/h
EBM-PAPST R2E180-CB28-01 Fan Blower, R2E Series, Motorized Impeller, 230 V, AC, 180 mm, 54.5 mm, 450 m³/h
- 2550/2800RPM Speed rating
- 60/75W Rated power
- 40/60°C Maximum ambient temperature
- Current is 0.28A at 50Hz and 0.33A at 60Hz
- Noise level of 64dBA at 50Hz, 67dBA at 60Hz
- Ambient temperature is 60°C
Applications
HVAC
Product details
| Supply Voltage | 230V |
| Power Connection Type | 2 Lead Wires |
| Flow Rate - Metric | 450m³/h |
| Fan Frame Size | 180mm |
| Current Type | AC |
| Product Range | R2E Series |
| Flow Rate - Imperial | 291.35cu.ft/min |
| Blower Type | Motorized Impeller |
| Noise Rating | 75dBA |
| Power Rating | 60W |
| Bearing Type | Ball |
| External Depth | 54.5mm |
Other details
| Brand | EBM-PAPST |
| Part Number | R2E180-CB28-01 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Operating Instructions EN | |
