COILCRAFT MSS1048-224KLC Surface Mount Power Inductor, MSS1048 Series, 220 �H, 1.18 A, 670 mA, Shielded, 0.394 ohm
COILCRAFT MSS1048-224KLC Surface Mount Power Inductor, MSS1048 Series, 220 �H, 1.18 A, 670 mA, Shielded, 0.394 ohm
Applications
Automotive
Product details
| Inductance Tolerance | � 10% |
| RMS Current (Irms) | 1.18A |
| Saturation Current (Isat) | 670mA |
| Power Inductor Case | 10.2mm x 10mm x 4.8mm |
| Inductance | 220�H |
| Inductor Construction | Shielded |
| Product Range | MSS1048 Series |
| DC Resistance Max | 0.394ohm |
| Packaging | Cut Tape |
Other details
| Brand | COILCRAFT |
| Part Number | MSS1048-224KLC |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
