Zacuto ACT Baseplate
Mount your DSLR or mirrorless camera and additional accessories such as a matte box, follow focus, or extension arms using the ACT Baseplate from Zacuto . The baseplate features a built-in shoulder pad, an Arca-type mounting plate, a quick release Arca-type camera plate, 15mm rod ports on the front and back, two 15mm rods, and stylish red locking levers all around.
The 15mm rods can be installed in the front or back of the plate, and they are secured with a quick release design. The Arca-type bottom plate can be mounted onto the ACT Mounting Plate or other Arca-compatible mounts. The red Arca-type camera plate features quick release functionality, pads to prevent twisting or slipping, and it's inset into the baseplate for a low-profile design. Scale markings along the top assist with balancing.
Key Features- 15mm LWS front and rear rod ports
- Arca-style quick release plate
- 1/4"-20 and 3/8"-16 tripod mount holes
- Buit-in ergonomic shoulder pad
- Two 15mm rods
- Scale markings for balance
| Support Type | Baseplate, Handheld Support, Rod Support System, Shoulder Support |
| Grip Type | None |
| Camera Compatibility | Universal |
| Rod Standard | 15 mm LWS / 60 mm Spacing |
| Battery Plate Type | None |
| Accessory Mounting | None |
| Camera Mounting | Arca-Type Plate with 1/4"-20 Screw, 3/8"-16 Screw |
| Tripod Mounting | Baseplate: 1/4"-20 Thread, 3/8"-16 Thread, Built-In Arca-Type Plate |
| Rod Ports | Baseplate, Front: 2 x 15 mm Rod Port |
| Shoe Mounting | None |
| Rosettes | None |
| Dimensions | 9 x 4 x 2" / 22.86 x 10.16 x 5.08 cm |
| Weight | Not Specified by Manufacturer |
| Package Weight | 2.695 lb |
| Box Dimensions (LxWxH) | 10.8 x 7.2 x 3.8" |
In the Box
- Zacuto ACT Baseplate
- Zacuto ACT Camera Plate
- 2 x 15mm Rod
- Limited Lifetime Warranty
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
