WURTH ELEKTRONIK 7443551181 Surface Mount Power Inductor, WE-HCI Series, 18 µH, 7.5 A, 7.5 A, Shielded, 0.022 ohm
WURTH ELEKTRONIK 7443551181 Surface Mount Power Inductor, WE-HCI Series, 18 µH, 7.5 A, 7.5 A, Shielded, 0.022 ohm
Product details
| Inductance Tolerance | ± 20% |
| RMS Current (Irms) | 7.5A |
| Saturation Current (Isat) | 7.5A |
| Power Inductor Case | 13.2mm x 12.8mm x 6.2mm |
| Inductance | 18µH |
| Inductor Construction | Shielded |
| Product Range | WE-HCI Series |
| DC Resistance Max | 0.022ohm |
| Packaging | Cut Tape |
Other details
| Brand | WURTH ELEKTRONIK |
| Part Number | 7443551181 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Original: $5.00
-70%$5.00
$1.50WURTH ELEKTRONIK 7443551181 Surface Mount Power Inductor, WE-HCI Series, 18 µH, 7.5 A, 7.5 A, Shielded, 0.022 ohm
Product details
| Inductance Tolerance | ± 20% |
| RMS Current (Irms) | 7.5A |
| Saturation Current (Isat) | 7.5A |
| Power Inductor Case | 13.2mm x 12.8mm x 6.2mm |
| Inductance | 18µH |
| Inductor Construction | Shielded |
| Product Range | WE-HCI Series |
| DC Resistance Max | 0.022ohm |
| Packaging | Cut Tape |
Other details
| Brand | WURTH ELEKTRONIK |
| Part Number | 7443551181 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
