Teradek Ranger Micro 5000 3G-SDI/HDMI Wireless Receiver (Gold Mount)
HomeStore

Teradek Ranger Micro 5000 3G-SDI/HDMI Wireless Receiver (Gold Mount)

Teradek Ranger Micro 5000 3G-SDI/HDMI Wireless Receiver (Gold Mount)

Teradek Ranger Micro Overview

By Photo's
Jennifer Hahn

Transmit lossless HD video up to 5000' with the Ranger Micro 5000 3G-SDI/HDMI Wireless Receiver from Teradek. Redesigned for broadcast, event, drone, and handheld applications, this receiver can receive up to 1080p60 video over a wide 4.9 to 6.4 GHz wireless range, including licensed and unlicensed bands in the 6 GHz U-NII 5 spectrum, and it can output up to 1080p60 video over HDMI or 3G-SDI with 10-bit HDR support. The receiver unit supports a powerful signal that can travel up to 5000' line of sight. It also features five external antennas.

When pairing with a Ranger transmitter, this unit can receive up to 1080p60 video alongside up to five other receivers, and it features built-in AES-256 encryption protects your video from prying eyes. It can receive visually lossless video from any Ranger series receiver with zero delay. The receiver supports a desktop Launchpad software application or the Launchpad app for iOS or Android that easily connects via Bluetooth 5, which both provide a spectrum analyzer, channel selection tools, and remote configuration.

The unit is powered using a 2-pin DC input or via the included Gold mount battery plate, and there are 1/4"-20 and M3 mounting threads to mount onto a variety of cameras, cages, or rigs.

Key Features
Premium Wireless Hardware
State-of-the-art hardware. Designed for professional video production. The Ranger Series is powered by Teradek's Emmy and Academy Award-winning technology for zero-delay wireless video transmission. This model boasts a maximum range of 5000', and it works seamlessly within a variety of professional broadcast, sports, and ENG applications, including handheld gimbals, drones, and shoulder-mounted production cameras.
Ranger Compatibility
Pair any combination of Ranger TX and RX together, regardless of model. That means your production can quickly scale and operate a variety of Ranger systems best suited to your environment, despite differences in transmission range. Mixed Ranger systems operate with a range of the lowest paired model. 6 GHz operation requires support on both the TX and RX.
Zero Delay
When a delay in audio and video transmission is noticeable, it's nearly impossible to offer a lifelike experience. Ranger's patented zero-delay technology solves this problem. With Ranger, your audio and video signals are transmitted with ultra-low latency, even in 1080p60, providing a visually lossless and engaging experience for your viewers.
Configure Ranger from PC or Phone
  • Install the Launchpad app on your macOS or Windows computer, or on iOS/Android phone
  • Bluetooth 5 LE connection support
  • Pair transmitters and receivers with the touch of a button
  • Measure and analyze the frequency and amplitude of a signal
  • View live channel strength for licensed/unlicensed bands
  • Monitor your live RF spectrum bandwidth
Wide Transmission Frequency Range
With the number of wireless devices on the rise, and a limited amount of frequency bands to choose from, there is little room for your signal to move without interference or disruption. But with Ranger, you have options: 5 GHz for general use, licensed band frequencies for special events, and the new 6 GHz U-NII-5 band for 12 new channels of uncongested wireless spectrum.

In the Box

  • Teradek Ranger Micro 5000 3G-SDI/HDMI Wireless Receiver (Gold Mount)
  • 5 x 2 dBi Antenna
  • Gold Mount Battery Plate

    Teradek Ranger Micro Specs

    Key Specs
    Video I/O
    1x HDMI 2.0 Output
    1x BNC (3G-SDI) Output
    Embedded Audio
    HDMI: 2-Channel
    SDI: 2-Channel
    Latency
    < 0.01 ms
    Video Format
    HDMI (8/10-Bit 4:4:4/4:2:2 RGB, YCC)
    1080p: 60/59.94/50/30/29.97/25/24/23.98
    1080PsF: 30/29.97/25/24/23.98
    1080i: 60/59.94/50
    720p: 60/59.94/50
    576p: 50
    480p: 60/59.94
    576i: 60
    480i: 59.94
    SDI (10-Bit 4:2:2 YCC)
    1080p: 60/59.94/50/30/29.97/25/24/23.98
    1080i: 60/59.94/50
    720p: 60/59.94/50
    576p: 50
    576i: 50
    480p: 60/59.94
    480i: 59.94
    Battery Type
    1x Gold Mount
    Power Consumption
    11 W
    Mounting
    1x 1/4"-20 Female
    Inputs / Outputs
    Antenna I/O
    5x RP-SMA Female
    Video I/O
    1x HDMI 2.0 Output
    1x BNC (3G-SDI) Output
    Embedded Audio
    HDMI: 2-Channel
    SDI: 2-Channel
    Audio I/O
    No
    Power I/O
    1x LEMO 2-Pin (28 VDC) Input
    Other I/O
    1x USB-C (Firmware) Input
    Encryption
    256-Bit AES
    Wireless
    Wireless Range
    5000' / 1524 m (Line-of-Sight)
    Channel Bandwidth
    40 MHz, 20 MHz
    Frequency Range
    US: 5.92 to 6.42 GHz
    US: 4.85 to 5.15 GHz
    US: 5.35 to 5.47 GHz
    US: 5.85 to 5.92 GHz
    Non-DFS Frequencies
    US: 5.15 to 5.25 GHz
    US: 5.72 to 5.85 GHz
    DFS Frequencies
    US: 5.25 to 5.35 GHz
    US: 5.47 to 5.72 GHz
    Latency
    < 0.01 ms
    RF Power
    21 dBm
    Wi-Fi
    No
    Bluetooth
    5.0 LE
    Mobile App Compatible
    Yes: Android & iOS
    Functionality: Adjust Settings, Remote Control, Setup, View Live Feed
    Cellular Support
    No
    Format Support
    Video Format
    HDMI (8/10-Bit 4:4:4/4:2:2 RGB, YCC)
    1080p: 60/59.94/50/30/29.97/25/24/23.98
    1080PsF: 30/29.97/25/24/23.98
    1080i: 60/59.94/50
    720p: 60/59.94/50
    576p: 50
    480p: 60/59.94
    576i: 60
    480i: 59.94
    SDI (10-Bit 4:2:2 YCC)
    1080p: 60/59.94/50/30/29.97/25/24/23.98
    1080i: 60/59.94/50
    720p: 60/59.94/50
    576p: 50
    576i: 50
    480p: 60/59.94
    480i: 59.94
    Video Standard Compliance
    SMPTE 424M
    Audio Format
    2-Channel 24-Bit 48 kHz
    Wireless Video Compression
    Uncompressed
    Timecode Support
    Yes
    Power
    DC Input Power
    7 to 28 VDC
    Battery Type
    1x Gold Mount
    Power Consumption
    11 W
    Mounting
    Mounting
    1x 1/4"-20 Female
    Environmental
    Operating Temperature
    32 to 72°F / 0 to 40°C
    General
    Material of Construction
    Aluminum, Polycarbonate
    Dimensions
    4.8 x 3.7 x 1.1" / 122 x 94 x 27 mm
    Weight
    10.3 oz / 292 g

    All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
    $11,135.84
