Studio Technologies Model 206 Announcer's Console
Studio Technologies Model 206 Overview
The Studio Technologies Model 206 Announcer?s Console is a compact, table-top unit that combines analog and digital audio resources for today?s demanding broadcast environments. Designed for sports, eSports, live events, entertainment, and streaming applications, it provides professional-grade quality in a rugged steel enclosure that fits into space-constrained locations. The Model 206 integrates seamlessly into Dante audio-over-Ethernet systems with AES67 compatibility, while also offering direct microphone outputs for analog workflows. Its intuitive controls, excellent audio quality, and reliable build make it a powerful yet simple solution for single on-air positions.
Flexible Audio Integration
With four Dante transmitter (output) channels-one main and three talkback-the Model 206 makes it easy to integrate with Dante-compatible devices such as intercoms, consoles, and monitor systems. It also provides a direct analog mic-level output for direct connection to cameras or audio interfaces. Four Dante receiver (input) channels deliver cue signals, while an integrated sidetone function ensures talent confidence monitoring when required.
Intuitive Operation
Four pushbutton switches (main plus three talkback) and three rotary controls allow straightforward management of on-air and production audio. Red and green LEDs support clear status indication, with user-configurable options to suit different visual preferences. The headphone output supports multiple modes and connection types-headsets, headphones, or earpieces?with flexible monitoring assignments handled in the digital domain for precision and control.
PoE and Dante Simplicity
One PoE-enabled Ethernet connection powers the unit and carries bidirectional Dante audio. Setup is fast and efficient, using the rugged Neutrik etherCON RJ45 connector. Audio configuration is handled in software using Studio Technologies' STcontroller, which provides access to parameters such as mic gain, phantom power, sidetone, button behavior, and headphone routing.
Professional Performance
The Model 206 is engineered for low noise, wide dynamic range, and ample headroom. Its microphone preamp supports both dynamic and condenser mics with phantom power, while careful circuit design and robust components ensure dependable long-term operation. Firmware upgradability and Dante Domain Manager support help ensure compatibility with future workflows.
Details
- Dante audio-over-Ethernet technology with AES67 compatibility
- One main and three talkback Dante output channels
- Four Dante receiver input channels for talent cue (IFB) signals
- Direct analog microphone output for camera or console integration
- Integrated sidetone function for confidence monitoring
- Flexible 2-channel headphone output with five operating modes
- Four pushbutton switches with user-configurable operation
- Uses STcontroller software for configuration
- Power-over-Ethernet (PoE) powered
- Rugged steel enclosure, compact table-top form factor
Items Included
- Studio Technologies Model 206 Announcer's Console
- Limited 3-Year Manufacturer Warranty
Additional Resources
Studio Technologies Model 206 Specs
Inputs/Outputs
| USB I/O |
1 x USB-A Female Input
|
| Audio I/O |
1x XLR 3-Pin Mic Input
1x XLR 3-Pin Mic Output 1x 1/4" TRS Headphone Output |
| Remote Control |
Connector: 1/8" / 3.5 mm TRS
|
| Ethernet |
Connector: Neutrik etherCON RJ45
|
Wireless
| Mobile App Compatible |
No
|
Power
| Power Source |
PoE
|
| Power Consumption |
6.5 W
|
Physical
| Color |
Black
|
| Dimensions |
5.1 x 4.3 x 2.1" / 13 x 10.9 x 5.4 cm
|
| Weight |
1.2 lb / 0.5 kg
|
Packaging Info
| Package Weight |
1.655 lb
|
| Box Dimensions (LxWxH) |
8.5 x 7.3 x 4.2"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
