Samtec FTSH-104-01-L-DV-P-TR FTSH-104-01-L-DV-P-TR Pin Header Board-to-Board Wire-to-Board 1.27 mm 2 Rows 8 Contacts Surface Mount Ftsh

The FTSH series from Samtec are surface mount micro terminal strip headers. It mates with Samtec FFSD, FFTP, CLP and FLE series of connectors. These terminal strip headers are available in end shroud, end shroud with locking clip, end shroud with guide post, end shroud with board lock and ejector shroud option.

Pitch spacing is 1.27mm (2 to 50 contacts per row) with double row vertical mounting (-DV)
Operating temperature range of -55?C to 125?C
Contact material is phosphor bronze
Black liquid crystal polymer insulator material
10?" gold plated contacts
Complies with UL E111594 and CSA 090871
0
000 standards

Applications

Industrial

Other details

Brand	SAMTEC
Part Number	FTSH-104-01-L-DV-P-TR
Quantity	Each (Supplied on Full Reel)
Technical Data Sheet EN
Drawing EN

All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
