Rosco RoscoLED Variable PWM DMX Decoder (12 x 5A)
- Pre-Configured RoscoLED Control Box
- Standalone Decoder for Advanced Setups
- CE Rated
The 12 x 5A RoscoLED Variable PWM DMX Decoder from Rosco is a standalone decoder for those who require a setup with a separate advanced power supply. Using advanced microchip technology, the decoder converts the standard DMX512/1990 signal into the PWM signal used by RGB LED lights.
| Rated Voltage and Power | Input Voltage: 12 - 24 VDC Output Current: 12 x 5 A Output Power: 12 x (60-120 W) PWM Adjustment: 500 Hz - 30 kHz |
| DMX | DMX In/Out: 5-pin XLR, RJ45, wire terminals |
| Operating Temperature | -4F to +122°F / -20 to +50°C |
| IP Rating | IP20 |
| Ratings | CE |
| Dimensions | 6.54 x 3.93 x 1.5" / 166 x 100 x 38 mm |
| Weight | 1.25 lb / 0.6 kg |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
