MOLEX 26-61-4060 Pin Header, Power, 3.96 mm, 1 Rows, 6 Contacts, Through Hole Straight, KK 396 41791
MOLEX 26-61-4060 Pin Header, Power, 3.96 mm, 1 Rows, 6 Contacts, Through Hole Straight, KK 396 41791
Product Overview
The 26-61-4060 is a 6-position 1-row vertical through-hole PCB header with gold-plated brass contacts and a natural colour polyester insulator. It comes with friction lock. It mates with 2139 KK® crimp housing, 41695 KK® crimp housing, 6442 KK® crimp housing, 2145 PCB connector, 41815 PCB connector, 3069 KK® crimp housing. It is suitable for use with wire-to-board application.
- UL94V-0 flammability
- Maximum contact current is 7A
- Maximum voltage is 250V
Applications
Automotive, Communications & Networking, Consumer Electronics, Data / Computing, Industrial, Medical
Product details
Other details
| Brand | MOLEX |
| Part Number | 26-61-4060 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
