IOGEAR 2-Port HDMI Secure KVM Switch (TAA)
IOGEAR GCS1312 Overview
Control two secure computers using one USB console and one display at resolutions up to 3840 x 2160 at 30 Hz with the 2-Port HDMI Secure KVM Switch from IOGEAR. This switch features two CPU inputs, each of which has an HDMI 1.4 input, a USB-B keyboard/mouse input, a USB-B CAC (Common Access Card) input, and a 3.5mm speaker output. Available console connections include an HDMI 1.4 port, two USB-A keyboard/mouse ports, a USB-A CAC port, and a 3.5mm speaker jack. Built using a rugged, durable metal chassis, this switch supports Windows, Mac, Linux, and Sun operating systems.
2-Port Secure HDMI KVM Computer Switch - Protection Profile 3.0
IOGEAR's 2-Port HDMI Secure KVM Switch is NIAP-certified and compliant with PP3.0 (Protection Profile for Peripheral Sharing Switch version 3.0) requirements, satisfying the latest security requisites set by the U.S. Department of Defense for peripheral sharing switches.
Common criteria compliance ensures maximum information security while sharing a single set of approved HIDs - keyboards, mice, speakers, CAC readers, and Microsoft Biometric Readers - between multiple computers. Conformity with Protection Profile v3.0 certifies that non-approved USB peripherals will be rejected and cannot be connected to the Secure KVM, providing high-level security, protection, and data safekeeping.
Common criteria compliance ensures maximum information security while sharing a single set of approved HIDs - keyboards, mice, speakers, CAC readers, and Microsoft Biometric Readers - between multiple computers. Conformity with Protection Profile v3.0 certifies that non-approved USB peripherals will be rejected and cannot be connected to the Secure KVM, providing high-level security, protection, and data safekeeping.
Active Tamper-Proof System
The IOGEAR Secure KVM Switch's hardware security is comprised of tamper-evident seals, active chassis intrusion detection, and tamper-proof hardware. Embedded software security allows administrators to grant controlled USB port access for keyboards, mice, and other devices while ignoring commands from non-HIDs when switching between ports. The onboard software restricts mouse and hotkey commands while clearing the keyboard's buffer when switching ports while ensuring data travels isolated on each port preventing exposure.
With the combination of physical and software security, IOGEAR Secure KVM series consolidates multiple workstations with varying security classification levels using one keyboard, monitor, and mouse (KVM) console.
With the combination of physical and software security, IOGEAR Secure KVM series consolidates multiple workstations with varying security classification levels using one keyboard, monitor, and mouse (KVM) console.
Superior Video Quality
The 2-Port HDMI Secure KVM supports a single view display and 4K Ultra HD resolutions to 3840 x 2160 at 30 Hz.
Features
- NIAP-Certified PP3.0
- Validated to Protection Profile v3.0 for peripheral sharing switches
- CAC & biometrics support
- Dedicated peripheral port for authorized CAC readers only and supported biometrics readers (compatible with Microsoft LifeCam HD-3000 and Microsoft Fingerprint Reader)
- 2-Port HDMI Secure KVM Switch
- One USB console controls two secure computers
- 4K UHD video resolution
- 1920 x 1080 (Full HD); 4K UHD Resolution: 3840 x 2160 at 30 Hz
- Port selection via push-button for enhanced security
- Keyboard restrictions - OSD & hotkey methods are not allowed
- Isolated channel per port
- Unidirectional data flow restricts data leakage between connected computers
- Active chassis intrusion detection
- Compromising the unit's cover renders the switch inoperable
- Tamper-evident seals
- Visually detect attempts to gain access to switch's internal components
- Tamper-proof hardware
- Integrated circuits are soldered directly onto the circuit board to hinder component sabotage
- Non-reprogrammable firmware
- Prevents tampering and attempts to reprogram the switch's firmware
- Clears keyboard buffer
- Data clears automatically after transmission to switch and resets
- Analog speaker support
- Secure audio data input does not convert digital audio to analog audio
- Multiplatform support
- Windows 2000, Vista, 7, 8, 8.1, 10, Linux, macOS, and Sun
- Rugged metal enclosure
- Durable, full metal chassis
- Built-in, internal power supply
Requirements
Console
- HDMI monitor capable of the highest resolution that you will be using on any computer in the installation
- Standard 104-key wired USB or PS/2 keyboard
- Standard 2 or 3 button wired USB or PS/2 mouse
- Speaker (optional)
- USB Smart card or CAC reader (optional)
Computers
- An HDMI video output connector
- A USB-A port for keyboard and mouse
- A USB-A port for Smart Card or CAC reader (optional)
- A 3.5mm jack audio port for speaker (optional)
Cables
- Do not attach cables that have microphone or line-in audio inputs
Operating Systems
- Windows 2000, Vista, 7, 8, 8.1, and 10
- Linux: Kernel 2.6+, RedHat v6.0+, SuSE v8.2+, Mandriva (Mandrake) v9.0+
- UNIX: AIX v4.3+, FreeBSD v3.51+, Sun Solaris v9+
- Novell Netware v5.0+
- macOS 9+
- DOS v6.2+
UPC: 881317516244
Items Included
- IOGEAR 2-Port HDMI Secure KVM Switch (TAA)
- Power Cord
- Limited 4-Year Manufacturer Warranty
Additional Resources
IOGEAR GCS1312 Specs
Key Specs
| # of Systems Supported |
2
|
| KVM I/O |
2x HDMI 1.4 Female
2x USB-B (Keyboard/Mouse) Female 2x USB-B (CAC) Female 2x 1/8" / 3.5 mm Line-Out Female |
| Console I/O |
1x HDMI 1.4 Female
2x PS/2 (Keyboard/Mouse) Female 2x USB-A (Keyboard/Mouse) Female 1x USB-A (CAC) Female 1x 1/8" / 3.5 mm Line-Out Female |
| Supported Resolutions |
3840 x 2160 @ 30 Hz
1920 x 1080 |
General
| # of Systems Supported |
2
|
| KVM I/O |
2x HDMI 1.4 Female
2x USB-B (Keyboard/Mouse) Female 2x USB-B (CAC) Female 2x 1/8" / 3.5 mm Line-Out Female |
| Console I/O |
1x HDMI 1.4 Female
2x PS/2 (Keyboard/Mouse) Female 2x USB-A (Keyboard/Mouse) Female 1x USB-A (CAC) Female 1x 1/8" / 3.5 mm Line-Out Female |
| Supported Resolutions |
3840 x 2160 @ 30 Hz
1920 x 1080 |
| USB Keyboard/Mouse Emulation |
Yes
|
| OS Compatibility |
Windows 2000 to 10
macOS 9 or Later Linux UNIX |
Power
| Power Source |
AC Adapter
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz at 1 A
|
Physical
| Operating Conditions |
32 to 122°F / 0 to 50°C up to 80% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C
|
| Housing Material |
Metal
|
| Dimensions |
13.25 x 6 x 1.75" / 33.66 x 15.2 x 4.45 cm
|
| Weight |
3.65 lb / 1.66 kg
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
