HPE Networking Instant On AP22D Dual-Band Wi-Fi 6 Access Point (5-Pack)
HPE Networking AP22D Overview
Quickly outfit your business with extensive Wi-Fi coverage with this HPE Networking Instant On AP22D Dual-Band Wi-Fi 6 Access Point 5-Pack Bundle from .
Wi-Fi 6 Features
The AP22D features Orthogonal Frequency-Division Multiple Access (OFDMA), which allows access points to handle multiple Wi-Fi 6 capable clients on each channel simultaneously.
Target Wake Time (TWT) - Ideal for IoT devices that communicate infrequently, TWT establishes a schedule for when clients need to communicate with an AP. This reduces power consumption and can extend the battery life of clients.
Multi-User, Multiple Input, Multiple Output (MU-MIMO) allows the access point to simultaneously serve multiple clients.
UPC: 190017676289
Items Included
- 5 x HPE Networking Instant On AP22D Dual-Band Wi-Fi 6 Access Point
- Limited 2-Year Manufacturer Warranty
- Limited 90-Day Manufacturer Warranty (Phone & Chat Support)
Additional Resources
No additional resources available
HPE Networking AP22D Specs
Key Specs
| Wi-Fi |
Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (4 x 4)
|
| Throughput |
1700 Mb/s Total
5 GHz: 1200 Mb/s 2.4 GHz: 574 Mb/s |
| Inputs/Outputs |
1x RJ45 2.5 GbE WAN PoE+ (30 W, 802.3at)
2x RJ45 Gigabit Ethernet LAN |
Wireless
| Wi-Fi |
Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (4 x 4)
|
| Number of Antennas |
2x Internal
|
| Antenna Gain |
5.2 to 5.4 dBi
|
| Transmit Power |
21 dBm
|
| Antenna Placement |
Internal
|
| Bluetooth |
No
|
Performance
| Throughput |
1700 Mb/s Total
5 GHz: 1200 Mb/s 2.4 GHz: 574 Mb/s |
Interface
| Inputs/Outputs |
1x RJ45 2.5 GbE WAN PoE+ (30 W, 802.3at)
2x RJ45 Gigabit Ethernet LAN |
Security
| Guest Network Support |
Yes
|
| Wireless Security |
WPA2, WPA3
|
| Lock Slot |
No
|
Management
| Operation Modes |
Access Point
|
| Supported Clients |
75
|
| Mobile App Compatible |
Yes: Android & iOS
|
Hardware
| Supported IEEE Standards |
802.11ax
|
Electrical
| Power Consumption |
51 W
|
General
| Environmental Resistance |
No
|
| Operating Conditions |
32 to 104?F / 0 to 40?C
|
| Mount Options |
Wall
|
| Dimensions |
5.9 x 3.4 x 1.9" / 150 x 86 x 47 mm
|
| Weight |
12.7 oz / 360 g
|
Packaging Info
| Package Weight |
1.61 lb
|
| Box Dimensions (LxWxH) |
9 x 4.6 x 4.3"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
