Harwin M22-2035005 M22-2035005 Pin Header Right Angle Wire-to-Board 2 mm 1 Rows 50 Contacts Through Hole M22

The M22-2035005 is a 50-contact 2mm male SIL Pin Header with gold plated phosphor bronze contacts, gold plated termination and black UL94V-0 polyamide (nylon) 6T housing. The M22 series connector has 3.4mm PC tail, horizontal connector orientation and PC tail/through board connection type. It is suitable for use with 0.5mm square mating pin size.

• 1A Current rating
• 650VAC Voltage proof
• 20mR Maximum contact resistance
• 1000MR (initial) Minimum insulation resistance
• 300 operations Durability

Applications

Commercial, Industrial

Other details

Brand	HARWIN
Part Number	M22-2035005
Quantity	Each
3D Product Image EN
Drawing EN
Manufacturer Catalogue EN
