CAMDENBOSS CTB92VG/2S Pluggable Terminal Block, 5 mm, 2 Ways, 30 AWG, 12 AWG, 2.5 mmï¿½, Screw

The CTB92VG/2S is a 2-pole 320V/12A female pluggable rising clamp Terminal Block with UL94-V0 flame retardant PA green polarised moulding, tinned phosphor bronze pin/terminal, nickel copper flash brass rising clamp, M3 steel zinc plated captive screw, vertical orientation, 5mm pitch. It features anti solder wicking and guided pin alignment. It accepts 0.2 to 2.5mmï¿½ (30 to 12AWG) solid and stranded cable.

>=2.5kV Dielectric strength
4kV Impulse withstand voltage
0.5Nm Torque
1.4mm Recommended PCB hole size

Applications

Industrial

Product details

Wire Size AWG Max	12AWG
Wire Connection Method	Screw
Rated Current	12A
No. of Positions	2Ways
Conductor Area CSA	2.5mmï¿½
Product Range	CTB92VG Series
Pitch Spacing	5mm
Wire Size AWG Min	30AWG
Rated Voltage	320V

Other details

Brand	CAMDENBOSS
Part Number	CTB92VG/2S
Quantity	Each
Technical Data Sheet EN
