Name: BRIDGELUX BXRV-TR-2765G-10A0-B-23 COB LED, White, Round with Flat Top, 6500 K, 90 CRI, 1190 lm, 137 lm/W, 130°, 250 mA, 34.8 V, 8.7W
Brand: Tanotis
SKU: bridgelux-bxrv-tr-2765g-10a0-b-23-cob-led-white-round-with-flat-top-6500-k-90-cri-1190-lm-137-lm-w-130-deg-250-ma-34-8-v-8-7w
Availability: InStock

✨ New Arrivals Just Dropped!Explore

Home Store

BRIDGELUX BXRV-TR-2765G-10A0-B-23 COB LED, White, Round with Flat Top, 6500 K, 90 CRI, 1190 lm, 137 lm/W, 130°, 250 mA, 34.8 V, 8.7W

Product details

Technical Specifications

COB Colour

White

Power Rating

8.7W

Forward Current @ Test

250mA

Forward Voltage VF Typ

34.8V

COB Length

15.9mm

Opto Case Style

SMD-4, No Lead

Light Emitting Surface

9mm

Lens Shape

Round with Flat Top

Product Range

Vesta Gen 2 9mm Array BXRV Series

Colour Rendering Index Max

Luminous Flux @ Test

1190lm

Viewing Angle

130°

Nominal CCT (K)

6500 K

COB Width

15.9mm

Lumens / Watt @ Current Test

137lm/W

Lens Type

Height

1.65mm

SVHC

No SVHC (21-Jan-2025)

Other details

Brand	BRIDGELUX
Part Number	BXRV-TR-2765G-10A0-B-23
Quantity	Each
Technical Data Sheet EN
