AVMATRIX PTZ1270 Full HD PTZ Camera with PoE & 20x Optical Zoom
AVMATRIX PTZ1270 Overview
Add a powerful PTZ with HD video capture to your production with this PTZ1270 Full HD PTZ Camera with PoE & 20x Optical Zoom from AVMatrix. The PTZ1270 offers precision control and multiple output ports offering up to 1080p60 video, and it also supports PoE (Power-over-Ethernet). Designed for broadcast, security, and teleconferencing needs, the PTZ1270 also supports VISCA, PELCO-D, and PELCO-P control protocols. The integrated f/1.6-3.5 lens offers 20x optical and 10x digital zoom functions. This camera supports up to 1080p60 video output via HDMI and 3G-SDI and has a LAN port for streaming via RTMP, RTSP, or ONVIF. An NDI streaming option is available separately.
Power this PTZ camera using the the included 12 VDC adapter or via PoE (Power-over-Ethernet). Quick pan and tilt speeds and picture controls like brightness, color, saturation, contrast, sharpness, and gamma provide precision control of your images.
The PTZ1270 camera supports up to 255 presets with up to 10 selectable using the included IR remote control. A 1/4"-20 thread on the camera bottom can be used for mounting. The PTZ1270 also comes with an RS232 control cable.
Features
In the Box
- AVMATRIX PTZ1270 Full HD PTZ Camera with PoE & 20x Optical Zoom
- 12V Power Supply
- RS-232 Control Cable
- Remote Control
- Limited 1-Year Warranty
AVMATRIX PTZ1270 Specs
| Image Sensor | 1-Chip 1/2.8" CMOS Sensor |
| Sensor Resolution | Effective: 2.07 Megapixel |
| Signal-to-Noise Ratio | 55 dB |
| Minimum Illumination | 0.5 Lux |
| White Balance | 3000 to 6500K |
| Max Digital Zoom | 10x |
| Built-In ND Filter | None |
| Optical Zoom Ratio | 20x |
| Focal Length | 5.2 to 98mm |
| Field of View | 3.3 to 54.7° |
| Maximum Aperture | f/1.6 to 3.5 |
| Focus Control | Autofocus |
| Output Formats | SDI, HDMI: 1920 x 1080p at 25, 29.97, 30, 50, 59.94, 60 fps |
| IP Streaming | ONVIF, RTMP, RTSP: 1080p |
| Presets | 255 via RS-232, VISCA 10 via IR |
| Move Speed | Pan: 0.1 to 180°/sec Tilt: 0.1 to 80°/sec |
| Movement Range | Pan: 340° (-170 to 170°) Tilt: 120° (-30 to 90°) |
| Supported Control Protocols | Pelco-D Pelco-P VISCA |
| Video Output Connectors | 1 x HDMI Type A (HDBaseT) Female 1 x BNC (3G-SDI) Female |
| Audio I/O | 1 x 1/8" / 3.5 mm Stereo Line Level Input |
| Control Interface | 1 x RJ45 (Pelco-D, Pelco-P, VISCA) 1 x 8-Pin Mini-DIN (RS-232) Input 1 x 8-Pin Mini-DIN (RS-232) Output 1 x 2-Wire (RS-485) |
| PoE Support | Yes |
| Power Connectors | 1 x Barrel / Coaxial (12 VDC at 1 A) |
| Operating Temperature | 14 to 122°F / -10 to 50°C |
| Storage Temperature | 14 to 140°F / -10 to 60°C |
| Operating Humidity | 20 to 80% |
| Storage Humidity | 20 to 95% |
| Tripod Mounting Thread | 1 x 1/4"-20 Female |
| Dimensions | 6.6 x 5.9 x 5.9" / 167.5 x 150 x 150 mm |
| Weight | 3.08 lb / 1.4 kg |
| Package Weight | 4.365 lb |
| Box Dimensions (LxWxH) | 10.5 x 9.7 x 9.2" |
AVMATRIX PTZ1270 Reviews
