ASUS ROG LOKI SFX-L Platinum 1000W Modular Power Supply
HomeStore

ASUS ROG LOKI SFX-L Platinum 1000W Modular Power Supply

ASUS ROG LOKI SFX-L Platinum 1000W Modular Power Supply

ASUS ROG LOKI SFX-L Overview

Equip your rig with the extensive and powerful ASUS ROG LOKI SFX-L Platinum 1000W Modular Power Supply. With a unique small form factor with ample connectivity options, the ROG LOKI can support a wide range of gaming and performance-based components while adding a sense of style to your system.

Achieve up to 1000W of total output, giving you ample support for a wide range of powerful components backed by an 80 PLUS Platinum certification, which ensures optimal efficiency. Designed to fit in a wide range of cases thanks to the SFX-L form factor, you have additional room for your wires while also promoting proper airflow. Modular cable design enables you to pick and choose the cables you need for your system, reducing clutter and simplifying the cable management process. Aside from all the standard cables, a dedicated PCIe 5.0 16-pin cable is included, allowing you to connect high-end graphics cards.

Enhanced Cooling
Utilizing a specialty ROG heat sink design and a dual ball bearing axial-tech 120mm fan, the LOKI remains cool even under heavy loads, ensuring longevity backed by a 10-year limited warranty. To reduce noise output, the PWM-controlled fan shuts off automatically when the PSU is below 40%.
Maximized Power
Low-ESR Japanese capacitors improve efficiency, giving the LOKI an 80 PLUS Platinum certification. A 16-pin PCIe cable that can provide up to 600W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, bringing large-scale capabilities to small form factor rigs.
ARGB Illumination
The 120mm cooling fan features eight addressable LEDs that can be customized with an array of colors and effects that allow you to add to your system's vivid aesthetic.
UPC: 195553722049

Items Included

  • ASUS ROG LOKI SFX-L Platinum 1000W Modular Power Supply
  • Power Cable
  • Motherboard Power Cable
  • 2 x CPU Cables
  • PCIe Gen 5 Cable
  • PCIe 1-to-1 Cable
  • PCIe 1-to-2 Cable
  • 2 x SATA 1-to-3 Cables
  • Peripheral 1-to-4 Cable
  • ARGB Cable
  • ATX to SFX Adapter Bracket
  • Limited 10-Year Manufacturer Warranty

Additional Resources

No additional resources available

ASUS ROG LOKI SFX-L Specs

Connectivity
Total Connectors
1x 20+4-Pin ATX Motherboard
2x 4+4-Pin EPS CPU
1x 16-Pin PCIe (12VHPWR)
3x 8-Pin PCIe
6x 15-Pin SATA
4x 4-Pin Peripheral / Molex
Cable Design
Modular
Electrical
Total Wattage
1000 W
Number of +12 V Rails
1
Combined Power for +12 V
1000 W
Max Load for +12 V
83.3 A
Combined Power for +3.3/+5 V
110 W
Max Load for +3.3 V
20 A
Max Load for +5 V
20 A
Max Power for +5 Vsb
12.5 W
Max Load for +5 Vsb
2.5 A
Max Power for -12 V
9.6 W
Max Load for -12 V
0.8 A
Peak Power
1000 W
General
Efficiency Rating
80 PLUS Platinum
Active Power Factor Correction
No
Efficiency
90% at 20% Load
92% at 50% Load
89% at 100% Load
Cooling
Fan Size
120 mm
Bearing Type
Ball
Physical
Form Factor
SFX-L
Compliance
ATX 12 V v3.0
Protection
Over-Current Protection, Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Under-Voltage Protection
Certifications
RoHS
Dimensions
4.9 x 2.5 x 4.9" / 125 x 63.5 x 125 mm
Packaging Info
Package Weight
5.45 lb
Box Dimensions (LxWxH)
11.3 x 7.5 x 4"

All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
