4ms Shuffling Clock Multiplier Eurorack Module (4 HP, Black Panel)
HomeStore

4ms Shuffling Clock Multiplier Eurorack Module (4 HP, Black Panel)

4ms Shuffling Clock Multiplier Eurorack Module (4 HP, Black Panel)

4ms SCMKIT- BLACK PANEL Overview

Get creative with tempos using the black 4ms Shuffling Clock Multiplier Kit, a DIY Eurorack module that produces eight multiplied clock tempos from a single input clock. The multiplied clock signals range from x1 to x8 (x32 using the separately available breakout module) and include five slipped/shuffled/skipped clock outputs including x3, x4, x5, x6, x8, as well as three steady clock outputs including x1, x2, and x8.

The Rotate CV jack reassigns the multiplication number on all jacks, while the Slip CV causes particular beats to land ahead in time. The SCM Kit includes all the components needed to complete the module as well as a black panel.

Full DIY Kit
  • Includes all the parts necessary to build a full-featured QCD Expander
  • Intermediate/Advanced-Level Kit: Soldering proficiency required
  • Tools Needed (Not Included):
    • Soldering iron, solder
    • Flush snips
    • Needlenose pliers (for removing a component if you make a mistake)
    • 5/16" and 3/8? socket driver (optional: pliers will work too if you're careful)
    • Multimeter (for reading resistor values if you don't know the resistor color-code chart)
At a Glance
  • Multiply-by-1 to Multiply-by-32 (x32 with optional breakout module), on 8 output jacks
  • Five Slipped/Shuffled/Skipped clock outputs (S3, S4, S5, S6, S8). Each is based on a multiple of the input clock frequency (x3, x4, x5, x6, and x8, respectively)
  • Three steady clock outputs (x1, x2, and x8), which are not affected by Slip/Shuffle/Skip effects
  • CV Rotate jack to shift multiply-by amount on all jacks
  • CV Slip causes particular beats to land ahead in time
  • Connects to the SCM Breakout for controlling more features: Pulse Width, Shuffle pattern, Skip, Resync, Mute, and 4x Fast
  • ISP header: Connects to in-circuit programmer such as AVR ISP MKII for reprogramming code
  • Maximum input frequency 3 kHz
Jacks
  • Clock Input (3.5V to 15V clock, rising-edge triggered)
  • CV Rotate (0V to +5.1V input)
  • CV Slip (0V to +5.1V input)
  • Multiplied clock outputs (8 jacks where R is the CV rotation 0 to 7):
    • Multiply-by (1+R)
    • Multiply-by (2+R) and slip/shuffle/skip
    • Multiply-by (3+R) and slip/shuffle/skip
    • Multiply-by (4+R) and slip/shuffle/skip
    • Multiply-by (5+R) and slip/shuffle/skip
    • Multiply-by (6+R) and slip/shuffle/skip
    • Multiply-by (7+R) and slip/shuffle/skip
    • Multiply-by (8+R)
Eurorack Ready
  • 4 HP Eurorack format module
  • Maximum Depth: 1.39" (35mm)
  • Includes power ribbon cable with 16-pin Eurorack power header
  • Power consumption: +12V: 33mA, -12V: 4mA

Items Included

  • 4ms Shuffling Clock Multiplier Eurorack Module (4 HP, Black Panel)
  • Full DIY Kit Components
  • Eurorack Ribbon Power Cable
  • Set of Mounting Screws
  • Limited 1-Year Manufacturer Warranty

Not Included

Additional Resources

    4ms SCMKIT- BLACK PANEL Specs

    Key Specs
    Sound Generation
    Analog
    Maximum Polyphony
    Not Specified by Manufacturer
    Audio I/O
    No
    MIDI I/O
    No
    CV/Gate I/O
    2x 1/8" / 3.5 mm TS CV Input
    Patch Points
    No
    Eurorack Current Consumption
    33 mA on +12 V Rail
    4 mA on -12 V Rail
    Horizontal Pitch
    4 HP
    General
    Item Type
    Eurorack Module
    Sound Generation
    Analog
    Keyboard
    No
    Expression Controls
    No
    Number of Pads
    No
    Display
    No
    Sounds
    Maximum Polyphony
    Not Specified by Manufacturer
    Built-In Effects
    No
    Built-In Speaker
    No
    Synthesis
    Oscillators
    No
    Mixer
    No
    Amplifiers
    No
    Envelopes
    No
    Filters
    No
    Sequencing & Recording
    Sequencer
    No
    Arpeggiator
    No
    Connectivity
    Audio I/O
    No
    Pedal Support
    No
    MIDI I/O
    No
    CV/Gate I/O
    2x 1/8" / 3.5 mm TS CV Input
    Patch Points
    No
    Sync I/O
    1x 1/8" / 3.5 mm TS Clock Input
    8x 1/8" / 3.5 mm TS Clock Output
    Network I/O
    No
    USB I/O
    No
    Media/Memory Card Slot
    No
    Compatibility
    Included Software
    No
    Mobile App Compatible
    No
    Power
    Power Requirements
    Eurorack Power
    Eurorack Current Consumption
    33 mA on +12 V Rail
    4 mA on -12 V Rail
    Physical
    Color
    Black
    Horizontal Pitch
    4 HP
    Included Accessories
    No
    Packaging Info
    Package Weight
    0.28 lb
    Box Dimensions (LxWxH)
    6.45 x 5.3 x 1.85"

    All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
    $50.60

    Original: $168.67
